一、Technical parameter
1、Equipment name: PFG180-120type rolling machine
2、Usage: it is used for grinding cement clinker
3、Amount: One unit
4、Material name: Cement clinker and so on
5、integrated moisture: ≤1～1.5%
6、Feed size: ≤80mmoccupied 5%，
7Discharging size: ＜2mm，occupied above 60%
8、Production capacity 650～800 t/h, Average 650～800 t Maximum 800 t/h
9、Working system Continuous
10、Power supply method Voltage 10000V
YRKK630-6 motor model YRKK630-6
11、Arranging method Indoor
12、Required power 2x1250 kW
13、Roller diameter 1800mm
14、Roller width 1200mm
15、Roller rotary speed 18.5 r/min
16、Equipment weight ～235.0 t
17、 Manufacturer Jiangsu Pengfei Group Co., Ltd
二、 Scope of supply and specification of main components and parts
Scope of supply
1、Main machine: includes frame of bearing series, feeding device, torque support, hydraulic system, lubricating system
2、Main drive part: includes motor, reducer, coupling, and base;
3、 Others: includes motor start-up cabinet, foundation bolts, cooling device, electrode for wear-resisting repair welding 10kg, special tools along with the equipments. The detailed scope of supply is based on the general drawings (drawing no) and unit assembly drawings supplied by Jiangsu Pengfei Group Co.,Ltd , every unit mainly includes:
1）Main frame
2）Main shaft
3）Bearing base
4）Main bearing
5）Reducer
6）Main motor
7）Cardan joint driving shaft
8）Motor base
9）Hydraulic system
10）Foundation bolts
11）Automatic grease lubricating system (including electric filling pump)
Technical documents and time supplied by the supplier
1. General assembly drawing two sets
2. Operating instruction manual one set
3. Packing list one set
4. In the above documents the first item is supplied to the buyer after signing the contract within one week and it is in duplicate, others will be supplied to the buyer when deliver the goods.
V type scatter classifier text
1、. Technical parameter
1、Equipment name PFV4000 type classifier
2、Usage It is used for scattering and classifying the separating, extrusion materials
3、Amount One unit
4、Material name Fresh material and extrusion materials
5、Integrated moisture ≤1～1.5%
6、Feed size Dmax≤30mm
7、Discharge size ≤0.5mm
8、Production capacity Average 800～950 t/h
9、Working system Continuous
10、Arranging method Indoor
11、Equipment weight 40t
12、Manufacturer Jiangsu Pengfei Group Co., Ltd
II. Scope of supply and specification of main components and parts
Scope of supply: Shell, shell liners, diaphragm for scattering. The detailed scope of supply is based on the general drawing (Drawing no) and unit general drawing supplied by Pengfei Group.
Every unit main include:
1. Shell
2. Shell liners and diaphragm for scattering
III. Technical documents and times supplied by the supplier
1. General assembly drawing for V type classifier one set
2. Packing list one set
In the above documents the first item is supplied to the buyer after signing the contract within one week and it is in duplicate, others will be supplied to the buyer when deliver the goods.
=========================================================================================================
