Production capacity: 140-150t/h（Feed size≤25mm，Feed integrated moisture≤1%，Feed temperature≤60℃，fineness of finished products≥3500cm2/g）
Rotary speed: 15.1r/min
Loading capacity of grinding body: 280t (Max 290t)
YRKK1000-8
Main motor YRKK1000-8
Main reducer JS160-C (Sichuan Gear)
Transmitted power: 4500Kw, Rated rotary speed: 745r/min，output rotary speed: 15.1r/min
Lubricating thin oil station of sliding shoe bearing
Model: XGD-A2.5x2/80
Amount: Two units
Main parameter:
High pressure pump: Y112M-6 Power2.2x2kW 2.5L/min 32MPa
Low pressure pump: Y112M-4 功率3x3kW 80L/min
Cooling water consumption of sliding shoe bearing: 2x4m3/h
Equipment weight:350tons (excludes motor, reducer and grinding body)
Parts weight and scope of supply
Feeding device (including supporting frame) 5930kg
Sliding shoe bearing (two sets)
Includes:
Supporting bush body: ZG270-500 5800kg Babbitt alloy ZSnSb11Cu6 500kg
Concave and convex sphere 34CrNi2MoA 1050kg
Spherical base ZG310-570 4500kg
Bottom plate Q235-B thickness 85mm 7200kg
Roller45 5600kg
Rotary part 287000kg
Includes:
Shell 103000kg
Mainly includes:
Shell steel plate Q235-C 115000kg
Slip spring of sliding shoe 20g-Z25 19800kgx2
Web of sliding shoe 20g 8950kgx2
Liner Chromium alloy
Discharging cover 17600kg
Lubricating system of sliding shoe bearing (two sets) 3980kg
6、Main motor YRKK1000-8
Rated rotary speed: 745r/min，rated power: 4500kW, rated pressure: 10KV
7、Reducer JS160-C （Sichuan Gear））
Transmitted power: 4500kW，Rated rotary speed：745r/min，Output rotary speed：15.1r/min
Weight of main reducer system: 110000kg
Total weight of equipment: 350000kg（excludes grinding body and driving device）
======================================================================================================================================
