Description of this cement mill:
Mill specification: Ф5x15 m
Grinding method: closed circuit (90%clinker, 5% Gypsum, 5% limestone)
Output: 150t/h (feeding material: ≤25mm90% passing)
Rotary speed: 14.5r/min
Loading capacity of grinding body:350t
Installed power: 6300KW
Driving method: Central drive
Total weight of equipment: **** t (exclude main motor, main reducer, sliding shoe lubricating station)
II. Weight and material of parts
Rotary part: Total weight: 387840㎏
Shell material: 20g Thickness of steel plate: 62mm
Sliding ring at feeding end and sliding ring at discharging end Material: 20g-Z25，20g
Double-diaphragm grate material: Chromium alloy cast steel
Discharging grate material: Chromium alloy cast steel
Liner Material: Chromium alloy cast steel
Support device for feeding sliding shoe
Support bush
Material of bush body: ZG270-500 Material for bush liner: ZSnSb11Cu6
Concave sphere and convex sphere Material: 34CrNi3MoA
Bottom plate Material: Q235B
Roller material: 45
Sliding shoe cover Material: structural parts
Supporting device of discharging sliding shoe
Supporting bush
Material of bush body: ZG270-500 Material of bush liner: ZSnSb11Cu6
Concave sphere and convex sphere Material: 34CrNi3MoA
Bottom plate Material: Q235B
Roller material: 45
Fixed block Material: HT200
Sliding shoe cover Material: structural parts
Feeding device Material: structural parts
Discharging cover: Material: Structural parts
Installation tools for sliding shoe
Lubricating oil station for sliding shoe bearing
Specification: GDRH-8/125 high and low pressure thin oil station two units
Model of motor of high pressure pump: ABB motor two units
Electromagnet 220V 5A one point
Power of motor of high pressure pump(KW): 5.5
Nominal pressure of high pressure pump (MPa):31.5
Nominal flow of high pressure pump: 8
Motor model of low pressure pump: ABB motor two units
Motor power of low pressure pump (KW): 5.5
Nominal pressure of low pressure pump (MPa): 1
Nominal flow of low pressure pump(L/Min): 125
Power of electric heater (KW): 4KW three units
Oil tank volume (M3): 2.5
Filtering accuracy (mm): 0.08
Media viscosity (C.S.T): N680
Media temperature（℃）： 40x3
Return oil temperature （℃）： ≤65
Cooling area (M2): 20
Cooling water temperature （℃）： ≤33
Cooling water pressure （MPa）： 0.4
Cooling water consumption （M3/h）: 11.25
Cooling water usage: cooling water consumption of sliding shoe bearing （M3/h）: 5X2
=================================================================================================================================================
