Description of Vertical Coal Mill:
This vertical coal mill is typically designed to process materials in medium hardness, like soft coal or bituminous coal, and it is mainly used in positive pressure pulverizing system of soft coal. It is widely used in electricity field, metallurgy sector, building material industry, chemical industry, and so on.
It has features of low energy consumption, small occupation area, easy operation, low noises, reliable performance, big crushing ratio, long-lifespan grinding components, strong applicability, and so on.
Technical Parameters of Vertical Coal Mill:
| Name | Unit | HRM1300M | HRM1400M | HRM1500M | HRM1700M | HRM1900M | |
| Grinding disc diameter | mm | Φ1300 | Φ1400 | Φ1500 | Φ1700 | Φ1900 | |
| Output | T/H | 10-15 | 12-17 | 16-22 | 20-28 | 26-35 | |
| Feeding | MM | 0-40 | 0-40 | 0-45 | 0-50 | 0-55 | |
| Feeding moisture | % | <15 | <15 | <15 | <15 | <15 | |
| Product fineness | % | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 | |
| Product moisture | % | <1 | <1 | <1 | <1 | <1 | |
| Power of main motor | KW | 200 | 200 | 280 | 315 | 400 | |
| Feeding temperature of air | ℃ | <450 | <450 | <450 | <450 | <450 | |
| Discharging temperature of air | ℃ | 80-95 | 80-95 | 80-95 | 80-95 | 80-95 | |
| Air discharging volume | M3/H | ~40000 | ~45000 | 65000 | 80000 | 100000 | |
| Weight | T | 45 | 52 | 75 | 96 | 100 | |
=============================================================================================================
As world-known and high-quality cement machinery general contractor, Jiangsu Pengfei Group Co., Ltd can provide you with various machines, such as cement production line, cement grinding plant, active lime production line, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, drying equipment, cooling equipment, compound fertilizer equipment, Conveying Lifting Packing Equipment, Most of our products have passed the certification of ISO9000 and CE, and they have been quite popular among customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Japan, South Korea, Bengal, Pakistan, Turkey, Vietnam, South Africa, Columbia, Bolivia, etc. If you need equipment such as rotary kiln, ball mill, vertical mill, rolling machine , please don't hesitate to contact us.
