Technical Parameters of Technical Parameters:
| Specification | Output (t/h) | Rotating speed of cylinder (r/min) | Loading capacity (t) | Main motor | Main speed reducer (kw) | Helper drive (kw) | Weight (kg) | |
| Model | Power | |||||||
| 1.5×3.0 | 2.0-2.5 | 24.5 | 6.5 | JR116-8 | 95 | ZD40-8-Ⅰ | 21.0 | |
| 1.7×3.5 | 3.5-7.0 | 24.5 | 11.0 | JR127-8 | 130 | ZD50-9-Ⅰ | 24.6 | |
| 2.0×4.0 | 5.0-10 | 23.9 | 18.0 | JR137-8 | 210 | ZD60-8-Ⅰ | 26.6 | |
| 2.2×4.4 | 5.0-9.0 | 23.9 | 19.0 | JR138-8 | 245 | ZD60-8-Ⅱ | 41.0 | |
| 2.4×4.75 | 11-18 | 20.9 | 26.0 | JR157-8 | 310 | ZD60-8-Ⅰ | 54.0 | |
| 2.4×6.0 | 12-16 | 20.2 | 28.0 | JR158-8 | 380 | ZD70-9-Ⅰ | 58.9 | |
| 2.6×5.0 | 9.0-13 | 21.0 | 25.0 | YR5005-8 | 450 | ZD70-9-Ⅰ | 68.0 | |
| 2.6×6.0 | 10-15 | 21.0 | 33.0 | JR1512-8 | 475 | ZD80-4.5 | 11 | 88.8 |
| 2.8×6.0 | 10-15 | 18.7 | 45.0 | JR1512-8 | 475 | MBY560 | 11 | 9536 |
| 2.8×7.0 | 18-35 | 18.7 | 38.0 | YR710-8 | 710 | MBY710 | 11 | 125 |
| 2.8×8.0 | 20-40 | 18.7 | 40.0 | YR800-8 | 800 | MBY710 | 15 | 131 |
| 3.0×6.0 | 15-25 | 19.4 | 68.0 | YR630-8 | 630 | MBY630 | 11 | 122 |
| 3.0×7.0 | 18-28 | 18.3 | 44.0 | YR710-8 | 710 | MBY710 | 11 | 132 |
| 3.0×9.0 | 20-30 | 18.3 | 18.0 | YR800-8 | 800 | MBY800 | 15 | 148 |
| 3.2×6.0 | 15-25 | 19.4 | 60.0 | YR800-8 | 800 | MBY710 | 15 | 132 |
| 3.2×7.0 | 18-30 | 18.3 | 88.0 | YR1000-8 | 1000 | MBY800 | 15 | 139 |
| 3.2×7.5 | 20-33 | 18.3 | 95.0 | YR1000-8 | 1000 | MBY800 | 15 | 144 |
| 3.5×6.0 | 20-35 | 17.3 | 59.0 | YR1000-8 | 1000 | MBY800 | 18.5 | 142 |
| 3.5×7.0 | 22-40 | 16.7 | 69.0 | YR1250-8 | 1250 | MBY900 | 18.5 | 155 |
| 3.5×8.0 | 22-40 | 16.7 | 69.0 | YR1250-8 | 1250 | MBY900 | 18.5 | 165 |
| 3.5×9.0 | 25-45 | 16.7 | 80.0 | YR1400-8 | 1400 | MBY900 | 22 | 174 |
| 3.6×6.1 | 25-45 | 17.3 | 71.0 | YR1250-8 | 1250 | MBY900 | 22 | 154 |
| 3.6×7.0 | 30-50 | 16.7 | 80.0 | YR1250-8 | 1250 | MBY900 | 22 | 176 |
| 3.6×8.0 | 33-55 | 16.7 | 85.0 | YR1400-8 | 1400 | MBY900 | 22 | 182 |
| 3.8×6.5 | 30-40 | 17.3 | 75.0 | YR1250-8 | 1250 | MBY900 | 22 | 186.5 |
| 3.8×7.5 | 35-48 | 17.3 | 85.0 | YR1400-8 | 1400 | MBY900 | 22 | 193 |
| 3.8×7.9 | 37-50 | 17.3 | 98.0 | YR1600-8 | 1600 | MBY1000 | 30 | 204 |
| 3.8×8.6 | 40-55 | 17.3 | 135 | YR1800-8 | 1800 | MBY1000 | 30 | 218 |
| 4.0×8.6 | 45-60 | 17.3 | 135 | YR1800-8 | 1800 | MBY1000 | 30 | 222 |
| 4.0×9.0 | 45-60 | 17.3 | 135 | YR2000-8 | 1800 | JDX1000 | 30 | 230 |
Note:
1. The feeding size is no more than 15mm.
2. The feeding moisture content is no more than 5.
3. The feeding temperature is ranging from 300 to 350℃, and the discharging temperature is 70℃.
=====================================================================================================================
As world-known and high-quality cement machinery general contractor, Jiangsu Pengfei Group Co., Ltd can provide you with various machines, such as cement production line, cement grinding plant, active lime production line, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, drying equipment, cooling equipment, compound fertilizer equipment, Conveying Lifting Packing Equipment, Most of our products have passed the certification of ISO9000 and CE, and they have been quite popular among customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Iran, Japan, South Korea, Bengal, Pakistan, Turkey, Burma, Vietnam, South Africa, Columbia, Bolivia, etc. If you need equipment such as rotary kiln, ball mill, vertical mill, rolling machine , please don't hesitate to contact us.
